ZEEMS I
Zenith's Electronic Engine Management Systems

Dual Fuel Injector

1. Throttle body with integrated electronic governing maintains precise engine speed control


   • Operates without the need for a throttle position sensor


   • System does not require external throttle linkage


   • Governor can maintain 3 set speeds plus idle speed (4 total operating speeds)


   • Unit can also be operated utilizing drive-by wire technology


   • The Electronic Control Unit (ECU) mounts directly to the fuel system throttle body and can control ignition timing and governing on DIS equipped engines


   • Engine can be easily de-rated (power) per application requirements or customers specifications


   • Customized PID settings allow superior governor control for each individual customer application


   • Tamper proof controls ensure continued optimum performance for life of system


2. Delivers only the amount of fuel the engine requires to operate efficiently under different load conditions


   • Better engine exhaust emission control (Enables engine manufacturers to meet emission requirements.)


   • Automatically compensates for altitude changes


   • Enhanced fuel economy


   • Closed loop system with O2 sensor for optimum 3-way catalysts emission performance



3. Enhanced engine performance over carburetors


   • Superior cold weather starting (Eliminates need for automatic and/or manual choke.)


   • Eliminates dieseling of engine on shutdown


   • Superior hot start performance



4. Compact size and design for easier application and installation of package


   • Designed to fit within current carburetor size envelope for easier installation


   • All electronic components are environmentally sealed and protected


   • Maximized use of automotive components and sensors for cost control and assurance of quality


   • Provision of EGR control if required by customer application


   • Diagnostics can be accomplished using a common 12 volt test light for field service


   • Capability for dashboard diagnostics can be added with software revisions


   • Easy calibration for different engine sizes and applications


   • Single throttle body design can accommodate 1 to 3 liter engines - gasoline or liquid propane


   • Engine manufacturer, distributor, or application builder can customize performance parameters



5. Can be used for various fuels: gasoline and liquid propane


   • Can be used for dual fuel applications


   • In-line fuel pump supplied as part of system provides easy installation and application flexibility



6. Dual Fuel system has capability of switching fuels on-the-fly while engine is running under load
